Swing Supermarket Barrier Gate Turnstile

The Swing Supermarket Barrier Gate Turnstile TH-SGB328 is a high-performance access control system designed for retail environments, ensuring secure and efficient customer flow management. Featuring a durable stainless steel construction, it offers smooth, bidirectional swing arm movement for seamless entry and exit.

Equipped with advanced anti-tailgating detection, the TH-SGB328 prevents unauthorized access while maintaining high throughput. Its customizable interface supports integration with POS systems, RFID cards, barcode scanners, and facial recognition for seamless checkout experiences.

Ideal for supermarkets, shopping malls, and high-traffic venues, this turnstile combines reliability with a sleek, modern design. It includes LED indicators and audible alarms for enhanced security and user guidance. With a low-power consumption motor and robust fail-safe mechanisms, it ensures continuous operation even during emergencies.

Key features:

• Smooth bidirectional swing arms

• Anti-tailgating & anti-reverse detection

• Multiple access control integrations

• Durable & weather-resistant build

• Audible & visual alerts

  Main Parameters
  1. Size: 1200 * 180 * 980 mm (can be customized)
  2. Max Arm length: 800 mm (can be customized)
  3. Housing Body material: 304 stainless steel
  4. Passing speed: 40 person/min
  5. Power supply: 110 V/220 V 50/60 Hz
  6. Driving Consumption: 20 W
  7. Gate Open Signal: Dry Contact/ Relay
  8. Swing barrier gate turnstile Driving Motor: 24 V
  9. Arm material : acrylic or steel optional


The TH-SGB328 enhances security, reduces revenue loss, and improves customer experience, making it an optimal choice for modern retail access control.
